Large Aluminum German Padel Court Tent
The Aluminum German Padel Court Tent is a robust, high-quality structure designed specifically for padel courts. Built with durable aluminum frames and weather-resistant PVC fabric, it provides a large clear-span interior without any central columns, ensuring unobstructed play space.This tent is customizable in size to fit single or multiple courts and is suitable for both indoor and outdoor use. Quick to install and dismantle, it offers an efficient and reliable shelter solution for clubs, sports centers, and private facilities. Optional features include glass walls, lighting, and flooring to enhance the playing environment.
Tent Series And Specifications:
Tent Series And Specifications.pdf
Specifications:
MMQ:200㎡
Orgin:Changzhou, Jiangsu, China
Span width:From 3 meters to 50 meters
Eave height:Standard from 2.5m, 3m, 4m to 5m upon width(or special height per requested)
Length:Unlimited, extended by 3m or 5m each bay
| Type | Width (m) | Bay distance (m) | Eave height (m) | Ridge height (m) | Main frame profile (mm) |
| MST-10 | 10 | 5 | 2.5 | 4.3 | 48x84x3/48x100x3 |
| MST-12 | 12 | 5 | 3 | 5.1 | 68x122x3 |
| MST-15 | 15 | 5 | 3 | 5.4 | 108x150x3 |
| MST-18 | 18 | 5 | 4 | 6.9 | 108x150x3/112x203x4 |
| MST-20 | 20 | 5 | 4 | 7.2 | 112x203x4 |
| MST-25 | 25 | 5 | 4 | 8 | 112x203x4 |
| MST-30 | 30 | 5 | 4 | 8.8 | 113x259x5 |
| MST-35 | 35 | 5 | 4 | 9.6 | 120x300x5 |
| MST-40 | 40 | 5 | 5 | 11.5 | 120x300x5 |
| MST-50 | 50 | 5 | 6 | 14 | 120x350x5.5 |
| The length can be extended by 5m bay such as 10m,15m,20m,25m,30m... | |||||
Competitive Advantage:
Modular type, the tent can be extended or dismantled to several small tents.
Easy to be assembled and dismantled.
No pole inside, 100% space available.
The aluminum frame will never get rusty with life span more than 15 years.
The PVC cover is waterprof, fireproof with life span 6-8 years.
Can be used in bad circumstance.
Key Attributes:
| Frame part | Main parts: aluminum alloy Spare parts:Durable galvanized steel. |
| All aluminum components are technically anodized and all steel parts are well hot-dip galvanized. | |
| Cover part | The roof and sidewall cover: double coated PVC fabric. |
| The weight of fabric is from 650g/sqm to 850g/sqm. | |
| Waterproof, UV resistant, flame retardant to DIN4102, M2 and Grade B1, tear resistant, self-cleaning ability, etc. | |
| Side wall | PVC wall, glass wall, sandwich panels, ABS panels,etc. |
| Fabric color option | White, transparent, green, yellow, red, blue, gray, black and customized |
| Applications | Wedding, events, temporary warehouse & workshop, exhibitions, church and other outdoor activities |
| Ground Situations | Grassland, sandy land, cement ground, marble ground, etc. |
| Fixing Solutions | Expansion screw, steel nail, weight plate, semi-permanent fixing, etc. |
| Wind load | 80-100km/h |
A-Type Tent Specifications:
Optional Accessories:
Tent Accessories
-
Flooring Type -
Simple Wooden Flooring -
Carpet Floor -
Rolling Gate -
Sandwich Wall -
ABS Wall -
Glass Wall -
Double Glass Door -
Lighting -
Steel Panel Wall -
Tables & Chairs -
Tables & Chairs
